Unleash Reliable Performance: Dual-Core CPU for Seamless Connectivity - For Outdoor Project
Z8105AX-M2-H is a 5G/4G+WiFi6 Outdoor CPE router, which can access the Internet through 5G/4G mobile communication dial-up or 1000Mbps WAN port, and then share the Internet network through wireless WiFi 6 and 1000Mbps/2.5G wired LAN.
HARDWARE FEATURES |
CPU | ARM Cortext-A53 dual-core CPU, main frequency up to 1.3GHZ |
Interface | 1G/2.5G Mbps WAN Port
3 *10/100/1000 Mbps LAN Ports 1 * m.2 slot
2 * Nano SIM Card Slot |
Button | Reset Button |
External Power Supply | 48V/0.5A Standard POE |
Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
Antenna | Built in 2* omnidirectional 8dbi 2.4G and 4G/5G external antennas Built in 2* omnidirectional 8dbi 5.8G and 4G/5G external antennas |
WIRELESS FEATURES |
Wireless Standards | IEEE 802.11a/n/ac/ax 5 GHz, IEEE 802.11b/g/n/ac/ax 2.4 GHz |
Frequency | 2.4 GHz and 5.8 GHz |
Signal Rate | 600Mbps at 2.4 GHz, 2400Mbps at 5.8 GHz |
Wi-Fi Max.Associated Clients | 128 |
WAN Failover | Yes |
Wireless Security | WPA/WPA2, WPA-PSK |
SOFTWARE FEATURES |
Channel adjustment | Support |
Power adjustment | Support |
Parent control | Support |
SSID Hidden | Support |
Black list | Support |
Cloud management | Support |
NTP | Support |
DHCP | Support |
VPN | Support |
Unleash High-Speed Connectivity: Z8105AX-M2-H Outdoor 5G CPE
Experience lightning-fast internet with the Z8105AX-M2-H. Enjoy seamless 5G/4G+WiFi6 connectivity for your outdoor adventures.
Powerful Performance: Dual-Core CPU
With an ARM Cortex-A53 dual-core CPU, the Z8105AX-M2-H ensures reliable performance for all your networking needs.
Secure and Versatile Networking: Feature-Rich Software
Benefit from customizable settings, VPN support, and more with the Z8105AX-M2-H's feature-rich software package.
