WG209 is a 5G/4G CPE product targeted at home. It accesses the Internet through 5G/4G mobile communication dial-up or 1000Mbps WAN port dial-up, and then shares the Internet network through wireless WiFi 5 and 1000Mbps wired LAN.
HARDWARE FEATURES |
CPU | MT7621 ,Dual Core, 880MHZ |
Interface | 1 * 10/100/1000 Mbps WAN Port
4 *10/100/1000 Mbps LAN Ports 1 * SIM Card Slot 1 * M.2 Slot 1 * USB 2.0 Port |
Button | Reset Button |
External Power Supply | Power Adapter: Input Power 100-240v~50/60 Hz 0.6A
Output parameter 12VDC 2A |
Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
Antenna | 8×Detachable High Gain Antennas |
WIRELESS FEATURES |
Wireless Standards | IEEE 802.11ac、IEEE 802.11a,IEEE 802.11n、IEEE 802.11g、IEEE 802.11b;IEEE 802.3,IEEE 802.3u |
Frequency | 2.4 GHz &5.8GHz |
Wireless Rate | 2.4G 300Mbps ,5.8G 867Mbps |
Wi-Fi Max.Associated Clients | 50 |
WAN Failover | Yes |
Wireless Security | WPA/WPA2, WPA-PSK |
SOFTWARE FEATURES |
WAN Type | PPPoE.Dynamic IP. Static IP |
Port Forwareding | Support |
Static Router | Support |
System Log | Support |
Parent control | Support |
SSID Hidden | Support |
Black list | Support |
Cloud management | Support |
NTP | Support |
DHCP | Support |
VPN | Support |
Unleash Ultra-Fast Connectivity with the WG209 Gigabit Dual Band 5G CPE
Elevate Your Home Network Experience
Experience lightning-fast connectivity with the WG209 Gigabit Dual Band 5G CPE. Tailored for home use, this router delivers high-speed internet access through 5G/4G mobile communication or a 1000Mbps WAN port. Share your internet network effortlessly through wireless WiFi 5 and a 1000Mbps wired LAN, ensuring seamless connectivity for your entire household.
Robust Hardware for Optimal Performance
Powered by a dual-core MT7621 CPU clocked at 880MHz, the WG209 ensures optimal performance for all your networking needs. With a comprehensive range of interfaces including one 10/100/1000 Mbps WAN Port, four 10/100/1000 Mbps LAN Ports, a SIM Card Slot, an M.2 Slot, and a USB 2.0 Port, this router offers versatile connectivity options to meet your specific requirements. Plus, with eight detachable high-gain antennas, enjoy extended coverage and superior signal strength throughout your home.
Seamless Connectivity, Enhanced Security
Enjoy seamless connectivity and enhanced security with the WG209 Gigabit Dual Band 5G CPE. Supporting wireless standards such as IEEE 802.11ac, IEEE 802.11a, IEEE 802.11n, IEEE 802.11g, and IEEE 802.11b, this router ensures compatibility with a wide range of devices. With a maximum associated clients capacity of 50 and support for WAN failover, stay connected effortlessly even during network interruptions. Plus, with advanced wireless security protocols like WPA/WPA2 and WPA-PSK, rest assured that your network is protected against unauthorized access.
