    Z8111AX-D – High-Performance WiFi 6 Router for Esports and Tech Office, 6-Antenna AX2975 Mesh USB 3.0 Gigabit

    MT7981B ARM Cortex-A53 Dual-Core CPU @ 1.3GHz for stable high-throughput routing

    MT7976CN WiFi 6 Chip: Up to 3000Mbps total (574Mbps @ 2.4G + 2400Mbps @ 5.8G)

    2.5Gbps PHY LAN Port: IEEE 802.3/802.3u/802.3ab/802.3bz — future-proof wired connectivity

    256MB DDR3 RAM + 128MB SPI NAND Flash (16MB NOR Flash optional)

    WiFi 6 OFDMA & MU-MIMO: 1024-QAM (2.4G) / 4096-QAM (5.8G), 2T2R / 2T3R

    OpenWRT Compatible: Full support for ZBT OS and OpenWRT firmware

    Dimensions: 204 × 182.2 × 75.48 mm | Color: Black

    OEM & ODM Router Solutions

    Hardware. Firmware. Software. One OEM/ODM Partner.

      WhatsApp Contact
      View Full Details
      1 / 1
      Product Specifications
      CPU Main Chipset: MT7981B ARM Cortex-A53 Dual Core CPU, 1.3GHz Frequency
      WiFi Chip WIFI Chipset MT7976CN; IEEE 802.11n/g/b/a/ac/ax; 2.4GHz MAX 573Mbps / 5.8GHz MAX 2402Mbps / Total 2975Mbps
      RAM DDR3 256MB
      Flash SPI NAND Flash 128MB / Nor Flash 16MB (option)
      LAN Port 1*1000Mbps WAN Port / 3*1000Mbps LAN Ports; 1*DC 5.5*2.1MM, 1*USB 3.0 Port; 1*Reset button, 1*Mesh button; 6*External Antennas
      Color Black
      Dimensions (L×W×H) 204 × 182.2 × 75.48 mm
      Documents
      Product Specification Download
      Specification Sheet Download
      Safety Guide Download

      Service & Support

      Inquiry-Within 24 hours
      Submit your router requirements and specifications. Our team reviews your request and provides preliminary feedback on feasibility and timeline.

      Solution Development-1-3 days
      We develop a customized solution based on your needs, including technical specifications, feature recommendations, and preliminary pricing.

      Engineering Design-3-7 days
      Our engineering team designs custom firmware, hardware improvements, and integration protocols specific to your application.

      Prototyping and Testing-7-15 days
      We manufacture prototype units and conduct comprehensive testing, including performance validation, compatibility checks, and quality assurance.

      Customization-3-10 days
      Fine-tune router configuration based on test results. Adjust specifications, optimize performance, and implement your branding requirements.

      Mass Production-15-30 days
      Begin full-scale production with quality control at every stage. We ensure consistency and reliability across all units.

      Delivery and Support-Ongoing support
      Ship your customized routers and provide comprehensive technical support, firmware updates, and warranty service throughout the product lifecycle.
